Normal Working Pressure: 7 Bar (100 PSI)
Free Air Delivery: 83 l/s (175 cfm) (5.0 m³/min)
Engine Brand: Kubota
Engine Model: V 1505 T
Engine Power: 33 kW (45 hp)
Engine Speed: Full load : 3000 rpm , Unload : 1850 rpm
Fuel Tank Capacity: 60 L
Compressor Oil Capacity: 8 L
Air Outlet Valves: 3 x G3/4
Operational Weight (Without Undercarriage): 650 kg
Operational Weight (With Undercarriage): 750 kg
Dimensions Without Undercarriage (LxWxH): 2050 x 1200 x 1200 mm
Dimensions With Undercarriage (LxWxH): 2700 x 1350 x 1350 mm
Electrical System: 12V
